About This

• Specifacation: SS304 Body with FKM Seals; Min. Relief Pressure of 30mBar; Temperature Range: -5°C to 100°C (approx.)
• The check valve is primarily used to prevent the backflow of air into the system after the pump has been turned off. It is typically installed on the discharge side of the pump and can prevent oil from flowing backwards when the pump is closed or experiencing a malfunction.
• The check valve is designed with a spring and valve seat O-ring, making it suitable for installation in any orientation
• Application: Vacuum pumps, molecular pumps, negative pressure equipment and other instruments

Overview

• Material : Stainless Steel
• Brand : QiiMii
• Item dimensions L x W x H : 3 x 2 x 2 inches
• Exterior Finish : Stainless Steel
• Inlet Connection Size : 4E+1 Millimeters
• Inlet Connection Type : KF-40
• Outlet Connection Type : KF-40
• Maximum Operating Pressure : 30 Millibars
• Number of Ports : 2
• Outlet Connection Size : 4E+1 Millimeters
